INVERTER TIG FOX TV3000 3000W

TIG FOX TV3000 3000W INVERTER

The TIGFOX TV3000 is a 3000w pure sine wave hybrid inverter with a built in charger and UPS function and Wifi connectivity for monitoring. This means that it is a single unit with a built in battery charger and inverter which can draw power from solar panels, battery or 220v mains power.

It can be used either in an on grid or off grid application.

On grid Application:

The inverter can draw power from 220 mains or solar panels. The inverter switch between solar or mains power automatically, depending on how it has been programmed by the installer. In the event of load shedding, the inverter will switch over to battery power automatically.

Off Grid Application:

There is no 220v AC power available, and power is provided by solar panels in conjunction with a battery. The solar panels will provide power to the load and charge the battery simultaneously. The inverter will switch automatically to battery power at night or when solar intensity is low.

Features:

• Off grid.
• On grid with battery storage.
• Configurable AC/SOLAR Charger priority via LCD setting.
• Smart battery charger for optimized battery performance.
• Compatible with generator.
• Overload protection.
• Thermal overload protection.
• Low Battery Protection.
• Short circuit protection.
• 9 units can be connected in parallel.
• 3 units may be synchronised for 3 phase power.
• Wifi connectivity for monitoring.

Technical Specifications:

• Rated Power:                                      3000W
• Surge Power:                                      6000W
• System voltage:                                  51.2V
• Input Frequency Range:                   50Hz/60Hz
• Output AC Voltage:                            230VAC±3%
• PV terminal charging mode:            MPPT
• PV Voltage:                                          450V DC (max)
• PV Current:                                          100A (max)
• PV Power:                                             5000W (max)
• Charging Current:                              80A (max)
• Output Power Factor:                        cosΦ=1.0
• Efficiency(Peak):                                ≥95%
• Transfer Time:                                    10ms
• Wave form:                                          Pure sine wave
